(The article is concerned ENTIRELY with fixed seat boats. Sliding seat craft are another kettle of fish.) There are many sources offering a standard formula for oar length, but nearly all of them are based on a single variable: the boat's beam at the oarlocks. I'd known since I was a kid, splashing around in oddball rowing craft, that the problem was a polynomial equation.� In other words, you're all set if it's a rowboat of normal proportions in the 8-foot to foot range. If the formula spits out foot oars or something similarly impractical, you've probably got a strange case on your hands, and you should pause to wonder why. (Click below to enlarge the article or click here to read it.). Welcome to Salt Pond Rowing, Your Source for Skiffs, Rowboats, Shells and Rowing Accessories. Easy Boat Building Projects Advise Compared - Quick Systems Of Boat Building - Maxwell's Projects. It is like watching the skilled boat builders doing it and just should replicating it!� Free Plans for Single and Double Paddles, Free Oars and more. Why are these plans FREE? Because I want people to know just how good correctly proportioned touring paddles can be.� C-Size 'General Arrangement' of the Twisted Oyster class Smith Island Crab Skiff Racer, in rendered PDF form for study- FREE for a limited time! Tabletop Audio - Premium Ambient Audio. Original, 10 minute ambiences and music for Tabletop Role Playing Games. I was commissioned to build a miniature rowboat by a repeat customer. This video details what I came up with to make this happen. Painted with flat.

Oars are expensive. Scrap lumber is free. Here's a quick way to make oars out of two by fours and other scrap lumber. It's a lot quicker to do it than to read about it. More paddle and oar making projects: Here's the quickest way I know to make a paddle. How to make an Eskimo style kayak paddle from a 2x4 in 1. We're going to use this pencil to trace around something. We'll sharpen it toward one side so the line doesn't get offset by the thickness of the pencil.

Get one of those wide flat pencils from the lumberyard. Sharpen with a knife as shown so it's flat on one side and sharpened on the other side. Finish by rubbing it on a piece of sandpaper. Find an oar you like and a piece of thin scrap plywood or sheet metal to trace it on. Lay the oar on it. Pound some nails around the oar to keep it from moving.

Clamping it down would work also. Trace the oar onto the pattern. You can hold the pencil vertical by holding it against either a spirit bubble level or a square.

Cut out the pattern using a saw. I used a bandsaw. Use whatever saw you have. Don't cut yourself. A bandsaw is dangerous and cuts meat really well. Then sand down to the line with your favorite power sander.

You could skip the patternmaking step and trace right onto the lumber you're making oars from. Or you could make one oar freehand and trace that for your second oar. I'm making a pattern because I'm planning to make more oars later. I'm planning to let other people use the original oars I'm copying, so they'll probably get lost in some adventure.

Then I'll still have the pattern. Scavenge some lumber. Straight grain and small knots are good. I got some that had been used as forms for concrete. That stuff is usually decent under the grey scum. If your oar blade is too wide for your 2x4, don't worry about it. The stuff you cut off around the handle will be plenty to glue at the blade end to make it wide. Trace the pattern onto the lumber. My pattern turned out crooked. Either I traced a crooked oar or the pattern warped.

To cope with that I flipped the pattern over and traced it again. To get a straight oar, you can use either the outer lines, the inner lines, or the average between them. Saw out the oar around the lines. I used a Japanese pullsaw. Any saw will work.

The offcuts will get glued around the blade. If you use an oar pattern with a narrow blade or find wide wood, no gluing is required. I found a 2x8 for my second oar. Glue and clamp the offcuts to the side of the blade to make it wide enough. I used yellow waterbased "waterproof" glue. That needs a pretty tight fit.

If you use epoxy your joint doesn't have to fit so well. While the glue dries, go surfing. Some pals and I went kitesurfing at Point Reyes. Here's a hasty paddle we found washed up on the beach. Someone made it from a chunk of plywood. Maybe they make a habit of losing paddles, so they don't waste time making them. Or maybe they were in a hurry to get out to sea and they lost more than that.

Trace the blade onto the blank. Jane Lee uses the "guillotine" brand meat saw to saw out the blade. When she's done she still has fingers. Strive to do so well. Clamp down the oar so it can't jump around. Plane it to the shape you like. Feel the blade with your hand, then feel the blade of an oar you like. Your hand will tell you more about the blade shape than your eye will.

Save the shavings for your composting toilet. Do this when you're awake but not shaky from caffeine. Put a coarse grit sanding disk on your angle grinder. Wear dust mask and safety glasses. Sand the two views down to the line. Then grind all the corners flat as shown to make it an octagon. Then round those octagon edges. Sand the blades smooth. Octagon the shafts where they meet the blade. Leave the shaft square by the handle. You want as much weight as you can get there to balance the weight of the blades.

Don't paint the handles. Tradition says it's easier on the hands that way. Paint the rest with free paint from your town's toxic dropoff center or building reuse depot.

Hang the oars or rest them on nail points as seen here so you can paint both sides of the oar. These are "instant" oarlocks designed by Phil Bolger and "Dynamite" Payson. I made them from stainless steel rod, sheet, and wire. The string tethers keep them from sliding off the oars and getting lost. If the rubber hose is too tight or stiff to slide on, put it in hot water to soften and lubricate it.

Make the strap part of the oarlock big enough so the oar can pivot without bending or binding in the strap. Row so the oar pushes against the rod. Happy rowing! I made some oars from using this DIY article. I used a jig saw with a new blade instead of a band saw for the blade and I shaped it all using a hand plane, spoke shave, and draw knife. The handle was easier to do with the spoke shave and Diy Plywood Rowboat Youtube draw knife.

The 2x4s were ripped in half and then two 15 inch pieces were glued with polyurethane glue to the ends. Reply 6 years ago on Introduction. I would encourage you to place the oars so that the PULL from the rod. This is the way they are used in the Mediterranean and the Indian Ocean. There, a single thole pin and a grommet -or strop- are used to fix the oars. The oar is always placed on the side of the motion of the boat, so that the grommet pulls from the thole pin.

Just try it. I have made several sets of oars over the years. A lot of people tend to use a 2x4 they have stuck away someplace or even get the lumber yard 2x4's, but it would be well worth the investment to ask the lumber yard to get you nice "CLEAR" Spruce boards. They will be a lot lighter.

If you are going to be rowing any distance, the weight makes a big difference.
