Glued-lap plywood is one of the most attractive, efficient, and economical methods of boatbuilding. It lends itself to a wide range of designs � traditional and modern, simple and sophisticated � and builders of all levels of skill and experience. As the name implies, the method relies not on mechanical fastenings, but rather glued plank seams. The intention of this book is to describe and to illustrate in detail the procedures involved in building clinker plywood boats of varying types and sizes. I am well aware that many first-time boatbuilders must find it an intimidating experience to unfo. Clinker built (also known as lapstrake) is a method of boat building where the edges of hull planks overlap each other. Where necessary in larger craft, shorter planks can be joined end to end into a longer strake or hull plank. The technique developed in northern Europe and was successfully used by the Anglo-Saxons, Frisians, Scandinavians, and typical for the Hanseatic cog. A contrasting method, where plank edges are butted smoothly seam to seam, is known as carvel construction. myboat025 boatplans - boat kits - build your own boat, Cnc cut boat kits for home boat builders. build your own boat with one of our boat kits. everybody can build their own boat with our boat kits.. Sailing boat plans - fyne boat kits, Plans for building your own wooden sailing boat from scratch including dinghies, cabin cruisers, catamarans, trimarans and proas.. Building a wooden boat - youtube, Want to watch this again later? sign in to add this video to a playlist. featuring the build of a 12' glued lapstrake sailing dinghy. the shearwater was.� Build a clinker plywood boat. Free boat plans, free boatbuilding plans. Lillistone Wooden Boats: Glued-Lapstrake (Clinker) - Another Approach. Awo2: Building small motor boat. Denman marine specialises in custom wooden boat building and repair we.

Clinker Ply. It is a method used in Northern European countries for centuries and produces a hull with graceful, tapering curves to the planking which stand out to emphasize the shape of the boat. It is not an easy method of construction but is very satisfying when completed to a good standard. Although thought of as a method only to be used by experienced and skilled boat builders, we have had several first time builders employ it to create some lovely craft - it comes down to how much practice and learning the builder wants to do before starting.

Traditional clinker construction started with a few moulds erected onto a building area, the transom and inner stem plus a hog inner keel were added much like the set up for strip planking and then the plank shapes were taken off this basic set-up.

The process was repeated for successive planks allowing the edges to over lap thus :- Above - planks laid clinker, clencher or lapstrake fashion - the plank "lands" are the points where one plank laps another. Once the hull was planked, the hull was turned upright if it was built upside down and timbers were fitted - these were relatively narrow and thin strips of wood, steamed to make them supple and then bent over the inside of the boat across the planking.

These timbers were held in place by a copper nail and rove through the timber at each plank land - the copper nail often square in section was fitted into a drilled hole with it's head on the outside - whilst one man held a weight against the head to keep it in place, another man cut the nail to the correct length, fitted a rove a cupped disc onto the cut end of the nail and then "rivetted" the end of the nail over the rove - this is waht held the planks together.

With the advent of modern epoxies, this traditional process could be modified to make the construction simpler and stronger. The wood planking, rather than being solid often Larch, Mahogany etc was substituted with good quality marine plywood which is dimensionally stable and easier to get hold of than the required clear lengths of relatively thin solid wood.

Also, the seams between the planks, rather than being held together with copper nails against steamed timbers are glued with thickened epoxy producing a lighter weight shell construction which has the appearance of traditional clinker.

First a building jig is built using chipboard moulds section shapes - these are usually given with "corners" or lap points - is "cornered" shapes so that the clinker laps are pre-determined by the design.

Ribbands stringers are fitted into slots cut at the plank land positions on the moulds but are kept short of the inner stem and probably only fry butted against the forward side of the transom. The garboard and next 2 planks are in place - the ribbands help define the shape of the planks and give something to clamp the plank edges too - screws used to hold the planks together whilst the epoxy cures and which go into the ribbands, are later removed - it important that no glue comes between the inside face of the planks and the ribbands unless, of course, the ribbands are to be permanent stringers within the hull structure.

Above is a view inside the bow of a clinker Kane Beach Punt showing the inner stem attached to the hog. A similar bow on the outside - note 2 items here - first, the outer stem which has been laminated directly over the exposed edges of the plywood planks and second, the fact that the planks are all "flush" with one another at the stem - a similar view of the planking at the aft end would also show the planks "flush" with each other as they go over the transom.

If this was not done, the planks would stick out over each other with gaps needing filling with the inner stem and the wjole affair would look very ugly - to avoid this and end up with a nice flush appearance each plank has a "let" or "gain" cut into it. This is a tapering rebate which goes from nothing in depth a few feet back from the stem to full plank thickness depth right at the end of the plank.

The width of this "gain" is the width of the overlap between two adjacent planks - therefore one plank gradually sits in this rebate ending flush with it at the extreme end. Above is the hull of a clinker Islay Skiff Pandora by Rob Johnsey with the jig removed from it - the inner stem was laminated over a former attached to the first mould.
